Frigidaire FFLE4033QW User Manual

151
15.6 User Interface Test
Selector position Position 0, 12 o’clock, top center, the normal wash position
Purpose of the test Function of switches and buzzer
Activated components Buzzer with a switch change
UI behaviour Change switch positions and the buzzer beeps
Working conditions Drum stopped, Door unlocked
15.7 Hot Water Valve Test
Selector position Turn 1 clicks clockwise from the top
Purpose of the test Water loading from the hot water valve
Activated components Door lock, hot water valve, and Clutch Motor
UI behaviour None
Working conditions Door locked, water level lower then 140mm, for a maximum period of 5 minutes.
The clutch moves to the agitate position, if it is in spin..
15.8 Cold Water Valve Test
Selector position Turn 2 clicks clockwise from the top
Purpose of the test Water loading from the cold water valve
Activated components Door lock and cold water valve, Clutch Actuator
UI behaviour None
Working conditions Door locked, water level lower then 140mm, for a maximum period of 5 minutes.
The clutch moves to the agitate position, if it is in spin.
15.9 Door Lid Unlock Test
Selector position Turn 3 clicks clockwise from the top
Purpose of the test Deactivate the Door lock
Activated components Door lock
UI behaviour None
Working conditions Drum stopped
