Step: 2
Detach the Moisture Sensor Terminal and take it out.
11.6 Components Accessibility
from the Front Panel
1. Motor / Blower Assembly
2. Heater Assembly
3. Thermostat (Safety)
4. Inlet Thermal Limiter
5. Outlet Thermal Limiter
11.6.1 Motor / Blower
Accessibility
Step: 1
Loosen the screws (2) which are fixed to the Dryer Back
Panel (Motor Access Panel) and take out the Motor Access
Panel.
Step: 2
Push the Idler Arm Assembly (See Fig.1) against the spring
force and loosen the belt from the motor pulley Figs. 2a
and 2b. Then remove the belt from the front side of the
machine as shown in Fig.3.
To Next Page
