E13: Water leakage
E13
Wrong drain pipe position (siphon), Water leak, Water flow too low, Water inlet
valve, Pressure sensor or hose.
Checks to perform:
WARNING
Check that all the connectors are correctly inserted
Are the washing machine’s water lines efficient (leaking)?
Repair the water circuit and repeat the Diagnostic Cycle
to check for any further alarms.
Is the drain pipe positioned correctly and not causing the
siphon effect? (See Fig.1)
Repair the drain circuit and repeat the Diagnostic Cycle
to check for any further alarms.
Is the water supply proper? [Water pressure must be
between10 psi (0.69 bars) and 120 psi (8.27 bars), Pressure
difference between hot and cold cannot be more than
10psi.]
Make water supply proper and repeat the Diagnostic
Cycle to check for any further alarms.
Is the air tube connected properly (check also for kinking
and leaking)? (Disconnect the tubes and blow into them to
make sure the system is unobstructed) (See Fig. 2)
Replace / Repair the air tube and repeat the Diagnostic
Cycle to check for any further alarms.
Is the frequency of Pressure Sensor between 45 Hz to 45.5
Hz? (Measure it on the pressure sensor wiring connector at
Main Control Board when machine is powered with empty
tub (No water)) (See Fig.3)
Replace Pressure sensor and repeat the Diagnostic
Cycle to check for any further alarms.
Is the resistance measurement of the Solenoid valve
approximately 1375Ω ± 10%? (Measure it directly on the
Solenoid Valve terminal without wiring (See Fig. 4)
See Next Page
Replace the Solenoid Valve and repeat the Dagnostic
Cycle to check for any further alarms.
N
O
Y
E
S
Y
E
S
Y
E
S
Y
E
S
Y
E
S
NO
NO
NO
NO
NO
YES
