Step: 2
Detach the connector and loosen the screws (2) to separate
the Main Board Assembly from the cover as shown in Figs.
3 and 4
Step: 3
Detach the cover from the Main Control Board Assembly as
shown in Fig. 5b, and then detach the Connectors from the
Main Control Board Assembly as shown in Figs. 6a and 6b to
separate the Motor Control Board Assembly.
14.8 Lid / Top Panel Assembly
Accessibility
Step: 1
Remove the Softener and the Bleach Dispenser Cover as
shown in Fig.1.
Step: 2
Loosen the Softener and the Bleach Dispenser Screw
(See Fig. 2) which is fitted to the Top Panel, then push the
dispenser (See Fig. 3) to take it out from the Top Panel.
