4-60 469 Motor Management Relay GE Power Management
4.9 S8 RTD TEMPERATURE 4 SETPOINT PROGRAMMING
4
4.9.4 RTD 11
RTD 11 defaults to
"Other"
RTD type. The Other selection allows the RTD to be used to monitor any tempera-
ture that might be required, either for a process or additional bearings or other. There are individual alarm, high
alarm and trip configurations for this RTD. Trip voting has been added for extra reliability in the event of RTD
malfunction. If enabled, a second RTD must also exceed the trip temperature of the RTD being checked before
a trip will be issued. If the RTD is chosen to vote with itself, the voting feature is disabled. The RTD name may
be changed if desired.
y
RTD #11
y
[ENTER] for more
RTD #11 APPLICATION:
Other
Range: Stator, Bearing, Ambient, Other, None
RTD #11 NAME:
Range: 8 alphanumeric characters
RTD #11 ALARM:
Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
RTD #11 ALARM
TEMPERATURE: 80°C
Range: 1 to 250, step 1
RTD #7 HIGH ALARM:
Off
Range: Off, Latched, Unlatched
HIGH ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
RTD #11 HIGH ALARM
TEMPERATURE: 80°C
Range: 1 to 250, step 1
RTD #11 ALARM
EVENTS: Off
Range: On, Off
RTD #11 TRIP:
Off
Range: Off, Latched, Unlatched
RTD #11 TRIP VOTING:
RTD #11
Range: RTD #1, RTD #2, RTD #3, RTD #4, RTD #5, RTD #6,
RTD #7, RTD #8, RTD #9, RTD #10, RTD #11, RTD #12
ASSIGN TRIP RELAYS:
Trip
Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3,
Trip & Auxiliary3
RTD #11 TRIP
TEMPERATURE: 90°C
Range: 1 to 250, step 1
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
