GE Power Management 469 Motor Management Relay 5-7
5 ACTUAL VALUES 5.2 A1 STATUS
5
5.2.4 START BLOCKS
Any active blocking functions may be viewed here.
y
START BLOCKS
y
[ENTER] for more
NO START BLOCKS
ACTIVE
Range: N/A
Message seen when no start blocks are active
OVERLOAD LOCKOUT
BLOCK: 25 min.
Range: 0 to 500 min.
Message seen only after an overload trip
START INHIBIT BLOCK
LOCKOUT TIME: 20 min.
Range: 0 to 500 min.
STARTS/HOUR BLOCK
LOCKOUT TIME: 20 min.
Range: 0 to 60 min.
TIME BETWEEN STARTS
LOCKOUT TIME: 20 min.
Range: 0 to 500 min.
RESTART BLOCK
LOCKOUT: 1200 s
Range: 0 to 50000 sec.
BLOCK START
469 NOT PROGRAMMED
Range: N/A
Seen only if Phase CT Primary and Motor FLA not programmed
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
