GE 469 Manual

5-14 469 Motor Management Relay GE Power Management
5.3 A2 METERING DATA 5 ACTUAL VALUES
5
5.3.8 ANALOG INPUTS
The values for analog inputs are shown here. The name of the input and the units will reflect those pro-
grammed for each input.
If no analog inputs are programmed in
S12 ANALOG I/O \ ANALOG INPUT 1/2/3/4
, the following flash message will
appear when an attempt is made to enter this group of messages.
y
ANALOG INPUTS
y
[ENTER] for more
ANALOG I/P 1
0 Units
Range: –50000 to 50000
Message seen only if Analog Input is programmed
Message reflects Analog Input Name as programmed
ANALOG I/P 2
0 Units
Range: –50000 to 50000
Message seen only if Analog Input is programmed
Message reflects Analog Input Name as programmed
ANALOG I/P 3
0 Units
Range: –50000 to 50000
Message seen only if Analog Input is programmed
Message reflects Analog Input Name as programmed
ANALOG I/P 4
0 Units
Range: –50000 to 50000
Message seen only if Analog Input is programmed
Message reflects Analog Input Name as programmed
ANALOG 1-2
0 Percent
Range: –5100 to 4900%
Message seen only if Analog In Diff 1-2 set to %Diff
Message reflects Analog Input Name as programmed
ANALOG 1-2
0 Units
Range: –100000 to 100000
Message seen only if Analog In Diff 1-2 set to Abs Diff
Message reflects Analog Input Name as programmed
ANALOG 3-4
0 Percent
Range: –5100 to 4900%
Message seen only if Analog In Diff 3-4 set to %Diff
Message reflects Analog Input Name as programmed
ANALOG 3-4
0 Units
Range: –100000 to 100000
Message seen only if Analog In Diff 3-4 set to Abs Diff
Message reflects Analog Input Name as programmed
THIS FEATURE NOT
PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
