5.2 A1 STATUS 5 ACTUAL VALUES
5
5.2.5 DIGITAL INPUTS
The messages shown here may be used to monitor Digital Input status. This may be useful during relay testing
or during installation.
Digital Input states will read as shorted if assigned as a tachometer.
5.2.6 REAL TIME CLOCK
The time and date from the 469 real time clock may be viewed here.
y
DIGITAL INPUTS
y
[ENTER] for more
ACCESS
SWITCH STATE: Open
Range: Open, Shorted
TEST
SWITCH STATE: Open
Range: Open, Shorted
STARTER STATUS
SWITCH STATE: Open
Range: Open, Shorted
EMERGENCY RESTART
SWITCH STATE: Open
Range: Open, Shorted
REMOTE RESET
SWITCH STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT1 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT2 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT3 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT4 STATE: Open
Range: Open, Shorted
TRIP COIL
SUPERVISION: No Coil
Range: Coil, No Coil
y
REAL TIME CLOCK
y
[ENTER] for more
DATE: 01/01/1994
TIME: 12:00:00
Range: 01 to 12 / 01 to 31 / 1995 to 2094
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
NOTE
ENTER
ESCAPE
ð
ð
