GE Power Management 469 Motor Management Relay 4-79
4 SETPOINT PROGRAMMING 4.13 S12 ANALOG I/O
4
4.13.2 ANALOG INPUTS 1-4
y
ANALOG INPUT 1
y
[ENTER] for more
ANALOG INPUT 1:
Disabled
Range: Disabled, 4-20 mA, 0-20 mA, 0-1 mA
ANALOG INPUT 1 NAME:
Analog I/P 1
Range: 12 alphanumeric characters
ANALOG INPUT 1 UNITS:
Units
Range: 6 alphanumeric characters
ANALOG INPUT 1
MINIMUM: 0
Range: –50000 to 50000, step 1
ANALOG INPUT 1
MAXIMUM: 100
Range: –50000 to 50000, step 1
ANALOG INPUT 1 BLOCK
FROM START: 0 s
Range: 0 to 5000 sec., step 1
ANALOG INPUT 1
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
ANALOG INPUT 1 ALARM
LEVEL: 10 Units
Range: –50000 to 50000, step 1
Units will reflect Analog Input 1 Units as entered above
ANALOG INPUT 1 ALARM
PICKUP: Over
Range: Over, Under
ANALOG INPUT 1 ALARM
DELAY: 0.1 s
Range: 0.1 to 300.0 sec., step 0.1
ANALOG INPUT 1 ALARM
EVENTS: Off
Range: On, Off
ANALOG INPUT 1
TRIP: Off
Range: Off, Latched, Unlatched
ASSIGN TRIP RELAYS:
Trip
Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3
Trip & Auxiliary3
ANALOG INPUT 1 TRIP
LEVEL: 20 Units
Range: –50000 to 50000; Step: 1
Units will reflect Analog Input 1 Units as entered above
ANALOG INPUT 1 TRIP
PICKUP: Over
Range: Over, Under
ANALOG INPUT 1 TRIP
DELAY: 0.1 s
Range: 0.1 to 300.0 sec., step 0.1
