GE Power Management 469 Motor Management Relay 5-23
5 ACTUAL VALUES 5.6 A5 EVENT RECORDER
5
5.6 A5 EVENT RECORDER 5.6.1 EVENT01 TO EVENT40
y
[ENTER] EVENT 01
No Event
TIME OF EVENT 01:
00:00:00.0
Range: hour:minutes:seconds
DATE OF EVENT 01:
Jan. 01, 1992
Range: month day, year
MOTOR SPEED DURING
EVENT01: Low Speed
Range: High Speed, Low Speed
Seen only if the Two-Speed feature is enabled
TACHOMETER DURING
EVENT01: 0 RPM
Range: 0 to 3600 RPM
Seen only if a Digital Input is programmed as Tachometer
A: 0 B: 0
C: 0 A EVENT01
Range: 0 to 100000 A
MOTOR LOAD
EVENT01: 0.00 x FLA
Range: 0.00 to 20.00 x FLA
CURRENT UNBALANCE
EVENT01: 0%
Range: 0 to 100%
GROUND CURRENT
EVENT01: 0.00 A
Range: 0.00 to 5000.0 A
A: 0 B: 0
C: 0 A Diff. EV01
Range: 0 to 5000 A
Seen only if Phase Differential CT is programmed
HOTTEST STATOR
RTD: 0°C EVENT01
Range: –50 to 250°C, ---- (no RTD)
Seen only if at least 1 RTD is programmed as Stator
HOTTEST BEARING
RTD: 0°C EVENT01
Range: –50 to 250°C, ---- (no RTD)
Seen only if at least 1 RTD is programmed as Bearing
HOTTEST OTHER
RTD: 0°C EVENT01
Range: –50 to 250°C, ---- (no RTD)
Seen only if at least 1 RTD is programmed as Other
AMBIENT
RTD: 0°C EVENT01
Range: –50 to 250°C, ---- (no RTD)
Seen only if at least 1 RTD is programmed as Ambient
Vab: 0 Vbc: 0
Vca: 0 A EVENT01
Range: 0 to 20000 A
Seen only if VT Connection programmed as None
Van: 0 Vbn: 0
Vcn: 0 A EVENT01
Range: 0 to 20000 A
Seen only if VT Connection programmed as Wye
SYSTEM FREQUENCY
EVENT01: 0.00 Hz
Range: 0.00, 20.00 to 120.00 Hz
0kW0kVA
0 kvar EVENT01
Range: –50000 to 50000 kVA
Seen only if VT Connection programmed as None
POWER FACTOR
EVENT01: 0.00
Range: 0.01 to 0.99 Lead or Lag, 0.00, 1.00
Seen only if VT Connection programmed as None
TORQUE
EVENT01: 0.0 Nm
Range: 0 to 999999.9
Seen only if Torque Metering is Enabled
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
