GE Power Management 469 Motor Management Relay 5-19
5 ACTUAL VALUES 5.4 A3 LEARNED DATA
5
5.4.4 ANALOG IN MIN/MAX
The 469 will learn the minimum and maximum values of the analog inputs since they were last cleared. This
information can be cleared with the
S1 469 SETUP \ CLEAR DATA \ CLEAR ANALOG I/P MIN/MAX
setpoint. When the
data is cleared, the present value of each analog input will be loaded as a starting point for both minimum and
maximum. The name of the input and the units will reflect those programmed for each input.
If no Analog Inputs are programmed in
S12 ANALOG I/O
, the following flash message will appear when an
attempt is made to enter this group of messages.
y
ANALOG IN MIN/MAX
y
[ENTER] for more
ANALOG I/P 1
MIN: O Units
Range: –50000 to 50000. Not seen if Analog Input is set as
None. Reflects the Analog Input Name as programmed
ANALOG I/P 1
MAX: 0 Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 2
MIN: O Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 2
MAX: 0 Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 3
MIN: O Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 3
MAX: 0 Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 4
MIN: O Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
ANALOG I/P 4
MAX: 0 Units
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
THIS FEATURE NOT
PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
