4.5.3 FORCE OUTPUT RELAY
The output relays can be independently forced in static or dynamic mode. In static mode the selected relay will
operate as long as it is in the
"Enabled"
state. Only when the user enters
"Disabled"
will the selected relay reset. In
dynamic mode the user specifies the operate time (1 to 300 seconds) and the selected relay will operate for the
specified duration.
The
FORCE OUTPUT RELAY
option is NOT allowed when the selected relay output is already active due to trip or
alarm condition, when the 469 is in start block condition, or when the 469 is not in service.
IMPORTANT NOTE:
• The forced relay will override any trip or alarm conditions.
(i.e. when the relay is forced and trip occurs, the relay will still be enabled when the trip condition is
reset)
• Control power loss in the 469 will
reset
all forced relays.
y
FORCE OUTPUT RELAY
y
[ENTER] for more
OPERATE R1
RELAY: Disabled
Range: Disabled, Enabled
R1 OPERATE
TIME: Static
Range: Static, 1 to 300 s
OPERATE R2
RELAY: Disabled
Range: Disabled, Enabled
R2 OPERATE
TIME: Static
Range: Static, 1 to 300 s
OPERATE R3
RELAY: Disabled
Range: Disabled, Enabled
R3 OPERATE
TIME: Static
Range: Static, 1 to 300 s
OPERATE R4
RELAY: Disabled
Range: Disabled, Enabled
R4 OPERATE
TIME: Static
Range: Static, 1 to 300 s
OPERATE R5
RELAY: Disabled
Range: Disabled, Enabled
R5 OPERATE
TIME: Static
Range: Static, 1 to 300 s
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
