GE Power Management 469 Motor Management Relay 5-11
5 ACTUAL VALUES 5.3 A2 METERING DATA
5
5.3.3 VOLTAGE METERING
Measured voltage parameters will be displayed here.
If no VT connection type is programmed for the
S2 SYSTEM SETUP \ VOLTAGE SENSING \ VT CONNECTION TYPE
set-
point, the following flash message will appear when an attempt is made to enter this group of messages.
5.3.4 SPEED
If the Tachometer function is assigned to one of the digital inputs, the tachometer readout may be viewed here.
If no digital input is configured as tachometer in
S3 DIGITAL INPUTS \ ASSIGNABLE INPUT1/2/3/4
, the following flash
message will appear when an attempt is made to enter this group of messages.
y
VOLTAGE METERING
y
[ENTER] for more
Vab: 0 Vbc: 0
Vca: 0 Volts
Range: 0 to 20000 V
Not seen if VT Connection is programmed as None
AVERAGE LINE
VOLTAGE: 0 Volts
Range: 0 to 20000 V
Not seen if VT Connection is programmed as None
Van: 0 Vbn: 0
Vcn: 0 Volts
Range: 0 to 20000 V
Seen only if VT Connection is programmed as Wye
AVERAGE PHASE
VOLTAGE: 0 Volts
Range: 0 to 20000 V
Seen only if VT Connection is programmed as Wye
SYSTEM FREQUENCY:
0.00 Hz
Range: 0.00, 20.00 to 120.00 Hz
THIS FEATURE NOT
PROGRAMMED
y
SPEED
y
[ENTER] for more
TACHOMETER: 0 RPM
Range: 0 to 3600 RPM
Seen only if a Digital Input is configured as Tachometer
THIS FEATURE NOT
PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
