4.12 S11 MONITORING 4 SETPOINT PROGRAMMING
4
4.12.3 CURRENT, KW, KVAR, KVA DEMAND
y
CURRENT DEMAND
y
[ENTER] for more
CURRENT DEMAND
PERIOD: 15 min.
Range: 5 to 90 min., step 1
CURRENT DEMAND
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
CURRENT DEMAND
LIMIT: 100 A
Range: 10 to 100000 A, step 1
CURRENT DEMAND
ALARM EVENTS: Off
Range: On, Off
y
kW DEMAND
y
[ENTER] for more
kW DEMAND
PERIOD: 15 min.
Range: 5 to 90 min., step 1
kW DEMAND
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
kW DEMAND
LIMIT: 100 kW
Range: 1 to 50000 kW, step 1
kW DEMAND
ALARM EVENTS: Off
Range: On, Off
y
kvar DEMAND
y
[ENTER] for more
kvar DEMAND
PERIOD: 15 min.
Range: 5 to 90 min., step 1
kvar DEMAND
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
kvar DEMAND
LIMIT: 100 kvar
Range: 1 to 50000 kvar, step 1
kvar DEMAND
ALARM EVENTS: Off
Range: On, Off
y
kVA DEMAND
y
[ENTER] for more
kVA DEMAND
PERIOD: 15 min.
Range: 5 to 90 min., step 1
kVA DEMAND
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
kVA DEMAND
LIMIT: 100 kVA
Range: 1 to 50000 kVA, step: 1
kVA DEMAND
ALARM EVENTS: Off
Range: On, Off
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
