5 ACTUAL VALUES 5.3 A2 METERING DATA
5
5.3.7 DEMAND METERING
The values for current and power demand are shown here. Peak Demand information can be cleared using the
S1 469 SETUP \ CLEAR DATA \ CLEAR PEAK DEMAND DATA
setpoint. Demand is shown only for positive real and pos-
itive reactive power (+Watts and +vars).
y
DEMAND METERING
y
[ENTER] for more
CURRENT
DEMAND: 0 Amps
Range: 0 to 100000 A
REAL POWER
DEMAND: 0 kW
Range: 0 to 50000 kW
Message not seen if VT Ratio is programmed as None
REACTIVE POWER
DEMAND: 0 kvar
Range: 0 to 50000 kvar
Message not seen if VT Ratio is programmed as None
APPARENT POWER
DEMAND: 0 kVA
Range: 0 to 50000 kVA
Message not seen if VT Ratio is programmed as None
PEAK CURRENT
DEMAND: 0 Amps
Range: 0 to 100000 A
Message not seen if VT Ratio is programmed as None
PEAK REAL POWER
DEMAND: 0 kW
Range: 0 to 50000 kW
Message not seen if VT Ratio is programmed as None
PEAK REACTIVE POWER
DEMAND: 0 kvar
Range: 0 to 50000 kvar
Message not seen if VT Ratio is programmed as None
PEAK APPARENT POWER
DEMAND: 0 kVA
Range: 0 to 50000 kVA
Message not seen if VT Ratio is programmed as None
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
