4-70 469 Motor Management Relay GE Power Management
4.11 S10 POWER ELEMENTS 4 SETPOINT PROGRAMMING
4
4.11.5 REVERSE POWER
If enabled, once the magnitude of 3-phase total power exceeds the Pickup Level in the reverse direction (neg-
ative kW) for a period of time specified by the Delay, a trip or alarm will occur.
The minimum magnitude of power measurement is determined by the phase CT minimum of 5%
rated CT primary. If the level for reverse power is set below that level, a trip or alarm will only occur
once the phase current exceeds the 5% cutoff.
y
REVERSE POWER
y
[ENTER] for more
BLOCK REVERSE POWER
FROM START: 0 s
Range: 0 to 50000 sec., step 1
REVERSE POWER
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
REVERSE POWER ALARM
LEVEL: 2 kW
Range: 1 to 25000 kW, step 1
REVERSE POWER ALARM
DELAY: 1 s
Range: 0.2 to 30.0 sec., step 0.1
REVERSE POWER ALARM
EVENTS: Off
Range: On, Off
REVERSE POWER
TRIP: Off
Range: Off, Latched, Unlatched
ASSIGN TRIP RELAYS:
Trip
Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3,
Trip & Auxiliary3
REVERSE POWER TRIP
LEVEL: 1 kW
Range: 1 to 25000 kW, step 1
REVERSE POWER TRIP
DELAY: 1 s
Range: 0.2 to 30.0 sec., step 0.1
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
NOTE
