GE Power Management 469 Motor Management Relay 4-65
4 SETPOINT PROGRAMMING 4.10 S9 VOLTAGE ELEMENTS
4
4.10.4 FREQUENCY
Once the frequency of the phase AN or AB voltage (depending on wye or delta connection) is out of range of
the overfrequency and underfrequency setpoints, a trip or alarm will occur.
This feature may be useful for load shedding applications on large motors. It could also be used to load shed
an entire feeder if the trip was assigned to an upstream breaker.
y
FREQUENCY
y
[ENTER] for more
FREQUENCY
ALARM: Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
OVER FREQUENCY
ALARM LEVEL: 60.50 Hz
Range: 25.01 to 70.00 Hz, step 0.01
UNDER FREQUENCY
ALARM LEVEL: 59.50 Hz
Range: 20.00 to 60.00 Hz, step 0.01
FREQUENCY ALARM
DELAY: 1.0 s
Range: 0.0 to 60.0 sec., step 0.1
FREQUENCY ALARM
EVENTS: Off
Range: On, Off
FREQUENCY
TRIP: Off
Range: Off, Latched, Unlatched
ASSIGN TRIP RELAYS:
Trip
Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3,
Trip & Auxiliary3
OVER FREQUENCY
TRIP LEVEL: 60.50 Hz
Range: 25.01 to 70.00 Hz, step 0.01
UNDER FREQUENCY
TRIP LEVEL: 59.50 Hz
Range: 20.00 to 60.00 Hz, step 0.01
FREQUENCY
TRIP DELAY: 1.0 s
Range: 0.0 to 60.0 sec., step: 0.1
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
