4.2 S1 469 SETUP 4 SETPOINT PROGRAMMING

4.2.6 MESSAGE SCRATCHPAD

Up to 5 message screens can be programmed under the Message Scratchpad area. These messages may be

notes that pertain to the installation or the motor or any other information deemed pertinent by the user. In addi-

tion, these messages may be selected for scanning during default message display. This might be useful for

reminding operators to perform certain tasks. The messages may be entered from the communications ports

or through the keypad. The following procedure demonstrates the use of the message scratchpad:

1. Select the user message to be changed.

2. Press the decimal [

] key to enter text mode. An underline cursor will appear under the first character.

3. Use the / key to display the desired character. A space is selected like a character.

4. Press the decimal [.] key to advance to the next character. To skip over a character press the decimal key.

If an incorrect character is accidentally stored, press the decimal key enough times to scroll the cursor

around to the character.

5. When the desired message is displayed press to store or to quit. The message is now per-

manently stored. Press to cancel the altered message.

MESSAGE SCRATCHPAD

[ENTER] for more

TEXT 1
