GE Power Management 469 Motor Management Relay 4-61
4 SETPOINT PROGRAMMING 4.9 S8 RTD TEMPERATURE
4
4.9.5 RTD 12
RTDs 12 defaults to
"Ambient"
RTD type. The Ambient selection allows the RTD to be used to monitor ambient
temperature for input into the thermal model. This sensor is required for the Learned Cooling feature of the
thermal model (see Section 4.6: S5 THERMAL MODEL on page 4–26). There are individual alarm, high alarm
and trip configurations for this RTD. Trip voting has been added for extra reliability in the event of RTD mal-
function. If enabled, a second RTD must also exceed the trip temperature of the RTD being checked before a
trip will be issued. If the RTD is chosen to vote with itself, the voting feature is disabled. The RTD name may be
changed if desired.
y
RTD #12
y
[ENTER] for more
RTD #12 APPLICATION:
Ambient
Range: Stator, Bearing, Ambient, Other, None
RTD #12 NAME:
Range: 8 alphanumeric characters
RTD #12 ALARM:
Off
Range: Off, Latched, Unlatched
ASSIGN ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
RTD #12 ALARM
TEMPERATURE: 60°C
Range: 1 to 250, step 1
RTD #12 HIGH ALARM:
Off
Range: Off, Latched, Unlatched
HIGH ALARM RELAYS:
Alarm
Range: Alarm, Alarm & Auxiliary2, Alarm & Aux2 & Aux3,
Alarm & Auxiliary3, Auxiliary2, Aux2 & Aux3, Auxiliary3
RTD #12 HIGH ALARM
TEMPERATURE: 60°C
Range: 1 to 250, step 1
RTD #12 ALARM
EVENTS: Off
Range: On, Off
RTD #12 TRIP:
Off
Range: Off, Latched, Unlatched
RTD #12 TRIP VOTING:
RTD #12
Range:
RTD #1, RTD #2, RTD #3, RTD #4, RTD #5, RTD #6,
RTD #7, RTD #8, RTD #9, RTD #10, RTD #11, RTD #12
ASSIGN TRIP RELAYS:
Trip
Range: Trip, Trip & Auxiliary2, Trip & Aux2 & Aux3,
Trip & Auxiliary3
RTD #12 TRIP
TEMPERATURE: 80°C
Range: 1 to 250, step 1
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
