NX-507E technical specifications
Power supply specifications
Power supply voltage 12 V
Minimum/maximum voltage 9 V to 14 V
12 V DC Auxiliary power output (supplied from NetworX control panel or NX-320-I power supply)
Maximum current consumption 100 mA at 12 V restricted by NX-507E/NX-508E
Power consumption
Nominal 10 mA (no outputs active)
Maximum 311 mA (all relays active)
Note: PLUS current consumption of any device
attached to NX-507E
Relays 7 relays (NO or NC) rated 1 A at 30 V
General feature specifications
PCB Size Dimensions (width x height x depth) 154 x 69 x 20 mm
Operating temperature −10° C to +55 °C
Humidity Max 95% non condensing
Shipping Weight (PCB) 110 g
Environmental
EN 50131 grade and class Security Grade 2, Environmental Class II
ACE type Type B - Fixed
Certification CE
EN 50131-1 System requirements
EN 50131-3 Control and indicating equipment
Tested and certified by Telefication B.V.
NX-508E technical specifications
Power supply specifications
Power supply voltage 12 V
Minimum/maximum voltage 9 V to 14 V
12 V DC Auxiliary power output (supplied from NetworX control panel or NX-320-I power supply)
Maximum current consumption 100 mA at 12 V restricted by NX-507E/NX-508E
Power consumption
Nominal 10 mA (no outputs active)
Maximum 25 mA (all outputs active)
Note: PLUS current consumption of any device
attached to NX-508E
Outputs 8 open collector outputs, max. 100 mA, max. wire
length 3 meters
General feature specifications
PCB Size Dimensions (width x height x depth) 154 x 69 x 20 mm
Environmental Operating temperature −10° C to +55° C
