Glossary
Location Term Definition
9 NX-507/508E An expander board that increases the number of outputs
that can be used with the control panel.
A menu entry that groups NX-507E/NX-508E output
expander options.
9.1.1 Outputs A menu entry that groups options relating to
programmable outputs.
There are two types of outputs; relay and open collector.
The control panel includes up to four auxiliary outputs. The
NX-507E/NX-508E output expander provides additional
outputs.
9.1.1.1.1 Event Any occurrence such as system arming, faults and alarms.
A menu option that specifies which event activates an
output.
9.1.1.1.1.1 Alarms A NX-507/508E menu entry that groups together the alarm
events that can be selected to trigger an output.
9.1.1.1.1.2 Arm/Disarm A menu entry that groups the events that can be used to
trigger outputs.
9.1.1.1.1.3 Communications A menu entry that groups together the communication
events that can be selected to trigger an output.
9.1.1.1.1.4 Keypads A menu entry that groups the keypad events that trigger
an output.
9.1.1.1.1.5 Sirens A menu entry that groups together the siren events that
can be selected to trigger an output.
9.1.1.1.1.6 Tamper/Fault A menu entry that groups together the tamper and fault
events that can be selected to trigger an output.
9.1.1.1.1.7 Tests A menu entry that groups settings related to different tests.
These include tests such as automatic test calls, dynamic
battery tests and so on.
9.1.1.1.2 Zone/User A menu entry that specifies that the selected event must
occur on a specific zone or by a specific user.
9.1.1.1.3 Time Unit A menu option that specifies whether the outputs are
timed in minutes or seconds.
9.1.1.1.4 Time A menu option that sets the length of time for which an
output is activated. If it is set to 0, the output follows the
event.
9.1.1.1.5 Partitions A menu entry that lists the partitions assigned to the
selected output. The selected output can be triggered by
an event on these partitions.
9.1.1.1.6 Attributes A menu entry that groups the programmable attributes of
the selected output.
9.1.1.1.6.1 Latched A menu option that causes an output to remain activated
until a code is entered at the keypad.
