Location Term Definition
6.1.13 Reset Settings A menu option that defaults the selected proximity reader
to factory defaults.
Programming locations for the NX-1701E
LOCATION 0 Programming the Scan Functions (3 segments of binary data)
Location 0 is used to select the particular function(s) that are activated when a card is scanned. More
than one function may be selected. If more than one function is selected, they will execute in order
from function 1 to function 8.
Note: Functions 1-6 will be performed based on the user’s authority.
Segment 1 Single Scan Function {Single Beep}
Program the functions that are performed when a card is scanned {one beep}.
1. "On" to send Code Entry function to the control panel.
2. "On" to activate the Armed Away mode.
3. "On" to activate the Armed Stay mode.
4. "On" to send the Disarm function to the control panel.
5. "On" to send Auxiliary Function #1 to the control panel.
6. "On" to send Auxiliary Function #2 to the control panel.
7. "On" to broadcast an X-10 function (see Location 241 for programming).
8. "On" to send a Request To Exit (RTE); and activate the onboard open collector output.
(Default is “On”).
Note: Location 243, Segment 2 must be programmed with a valid zone number for the RTE to be sent.
Segment 2 Double Scan Function {Double Beep}
Program the functions that are performed when a card is scanned twice within the 2 Scan Hold Time
(two beeps). Location 244, Segment 1 programs the length of time between beeps. The descriptions
of the options are the same as for Single Beep Scan Function. Default is 1.
Segment 3 Single Scan Hold Function {Triple Beep}
Program the functions that are performed when a card is scanned and held at the reader for the
duration of the 2 Scan Hold Time {three beeps}. Location 244, Segment 1 programs the length of
time between beeps. The descriptions of the options are the same as for Single Beep Scan Function.
Default is 1.
