NX-10 Expander Installation Guide
113
3, 4, 5, 6, 7, 8 Extends the session time.
9 Turns both microphones on and extends the session time.
Output / relay control level (negative—turn off)
Note: This feature requires X-10 Interface.
0 Returns to the initial session settings when it is tripped. This includes the
microphone selection and audio mode.
Level
5
1 – 9 Turns the corresponding output/relay OFF. A negative confirmation tone (two low
beeps) is heard. For more information, see
Table 20. NX-534E tones.
Output / relay control level (positive—turn on)
Note: This feature requires X-10 Interface.
0 Returns to the initial session settings when it is tripped. This includes the
microphone selection and audio mode.
Level
6
1 - 9 Turns the corresponding output/relay ON. A positive tone sounds.
Status check
0 Returns to the initial session settings when it is tripped. This includes the
microphone selection and audio mode.
1 Armed status: If partition 1 is armed, a positive tone sounds. If disarmed, a
negative tone sounds.
2 Ready status: If partition is in Ready status, a positive tone sounds. If it is not
Ready, a negative tone sounds.
3 Power status: If AC and battery are good, a positive confirmation tone sounds. If
either AC or battery is bad, a negative tone sounds.
Level
7
4 – 9 Extends the session time.
Arming / disarming partition 1
Level
8
0 – 9 Enter your PIN user code to arm or disarm the system. If partition 1 is armed, a
positive beep sounds. If partition 1 is disarmed, a negative beep sounds.
Tones
These indicator tones may be heard at the central station during a two-way session. The definition of
these indicator tones is as follows:
LOW = 400 Hz
MID = 1000 Hz
HIGH = 1600 Hz
Table 14. NX-534E tones
Tone Description
