Segment 10 Activation data for user cards 193 – 200.
Segment 11 Activation data for user cards 201 – 208.
Segment 12 Activation data for user cards 209 – 216.
Segment 13 Activation data for user cards 217 – 224.
Segment 14 Activation data for user cards 225 – 232.
Segment 15 Activation data for user cards 233 – 240.
Location 43 Programming Logging Partition (1 segments of numerical data)
Segment 1
This location programs the partition that is logged with the Code Entry message and sent
when the following conditions are met:
• An RTE scan function is selected (Location 0, Segment 1/2/3, Option 8); and
• “RTE from a scanned card is to be logged as Code Entry” is enabled (Location 2, Segment
1, Option 5).
Entering a 0 (zero) will send the lowest valid partition of the reader. Entering 1-16 will send
the entered value as the partition. (Default is 0.)
Technical specifications
Power supply specifications
Power supply voltage 10.5-13.8V ± 2%
Consumption - Standby 40 mA at 13.8V ± 2%
Consumption – Maximum 110 mA at 13.8V ± 2%
General feature specifications
Reader Size Dimensions (width x height x depth) 80x80x15 mm
Environmental Operating temperature +0° C to + 49 °C
Humidity Max 93% non condensing
Shipping Weight 55 g
