3. The keypad beeps once to confirm the change and returns to Line Hold Digit.
4. Scroll to Timers>Line Hold Timeout and press OK.
5. Select 60 and press OK.
6. The keypad beeps once to confirm the change and returns to Line Hold Timeout.
Setting volume levels
You can adjust volume levels used with the NX-534E listen-in module. The following example sets
the volume for high gain listen in to level 4.
1. Navigate with the ½¾ keys to NX-534E>Volumes and press OK.
2. Scroll to High Gain Listen In>4 and press OK.
3. The keypad beeps once to accept the change and returns to High Gain Listen In.
Assigning X-10 devices
The NX-534E listen-in module can activate X-10 devices over the telephone. The following example
assigns device 1 (module number 5, house code L) to the NX-534E listen-in module.
1. Navigate with the ½¾ keys to NX-534E>Light Control>Device 1 and press OK.
2. Scroll to Unit Code and press OK.
3. Select 5 and press OK.
4. The keypad beeps once to confirm the change and returns to Unit Code.
5. Scroll to House Code and press OK.
6. Select L and press OK.
7. The keypad beeps once to confirm the change and returns to House Code.
Glossary
Location Term Definition
10 NX-534E Listen-in Module A two-way audio voice communicator. If the control panel
communicates an alarm, the audio module allows the
central station to establish a two-way session or monitor the
premises for listen-in purposes.
10.1 Feature Select A menu entry that groups all optional features relating to
partition settings, control panel system settings and so on.
10.1.1 Mode A menu option that specifies if the listen-in module is used in
line hold mode or call back mode.
10.1.2 Listen-in Only A menu option that enables the listen-in only mode. This is
the mode in which the central station can monitor sounds at
the customer's premises but cannot establish two-way
communication.
