GE NX-10 Installation Guide

Programming the NX-320-I auxiliary power module
Figure 9. NX-320-I menu structure
You must enrol and default the NX-320-I power module before you begin to program the system. For
more information on enrolling and defaulting, see Enrolling the NX-320-I auxiliary power module
above. To program the NX-320-I power module, select Installer Menu>NX-320-I Power Modules.
Configuring outputs
You can specify events and partitions that can activate a particular output. The outputs are triggered
based on different events. The events are grouped in the programming tree. A full list of all possible
selectable events can be found in
Table 23. NX-320-I output events. You can also assign a defined
attribute to the output. The following example enables user code 1 to reset the timer on output 1,
power module 84 when an autotest event occurs.
1. Navigate with the ½¾ keys to NX-320-I Power Modules>Power Module 84>Outputs
and press OK.
2. Scroll to Output 1>Event>Tests>Automatic Test and press OK.
3. The keypad beeps once to accept the change and returns to Tests.
4. Scroll to Attributes>Code Stops Timer>Yes and press OK.
5. The keypad beeps once to accept the change and returns to Code Stops Timer.
6. Navigate with the ½¾ keys to Users>(1) User 1>Outputs> and press OK.
7. Press the relevant keys to select output 1 only and press OK.
Time Unit
Time
Partitions
OutputsPower Module 84
Feature Select Mains Delay Time
Battery Test
Battery Test Time
Reports
1 (<Event>) Event Alarms
Arm/Disarm
Communications
Keypads
Sirens
Tamper / Fau l t
Tes ts
Miscellaneous
Attributes
Latched
Code Stops Timer
Inverted
Disable on Listen-in
Report Mains Fail Always
Low Battery
Siren Tamper/Fault
Users (1) User 1 Outputs
8.1
8.1.1
8.1.2
8.1.3
8.1.4
8.1.5
8.1.6
8.1.1.1
8.1.2.1
8.1.3.1
8.1.3.3
8.1.3.2
8.1.3.4
8.1.1.1.1
8.1.1.1.2
8.1.1.1.3
8.1.1.1.4
8.1.1.1.5
8.1.2.1.1
8.1.3.4.1
8.1.3.4.2
8.1.3.4.3
8.1.1.1.1.1
8.1.1.1.1.8
8.1.1.1.1.7
8.1.1.1.1.6
8.1.1.1.1.5
8.1.1.1.1.4
8.1.1.1.1.3
8.1.1.1.1.2
8.1.1.1.5.1
8.1.1.1.5.4
8.1.1.1.5.3
8.1.1.1.5.2
Power Modules 85 - 91
Same as above
Outputs 2 - 3
Same as above
Users 2 - 99
Same as above
If more than 10 users,
users are first displayed in
groups of 10 and then
displayed as above.
Model
Version
Reset Settings
