Google Home User Manual

Set up your Google Home
Power jack
Located at the back of
the device is a micro
USB input to power it
LEDs
Four LED lights change
colour and pulse to
indicate what it is doing
Volume
controls
Adjust the Mini’s
volume by tapping
on either side of
the device
Colours
The Google Home
Mini comes in three
colours: Chalk,
Charcoal and Coral
Touch surface
Control the device by
tapping, pressing or
swiping on this
Speakers and
microphones
The Google Home has two
microphones as well as one driver
and two passive radiator speakers
Mute
button
Stop the Home
from listening
by tapping the
button located
at the back
LED Ring
This will light
up differently
depending on
what the Google
Home is doing
Set up your
Google Home
The Google Home is a powerful device, but its not
complicated to set up, especially with our instructions
How to...
16

Google Home Specifications

General

Speaker type	-
Driver diameter	50.8 mm
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Product color	White
Housing material	Fabric
Hands-free mode	Yes
RMS rated power	- W
Audio formats supported	FLAC, HE-AAC, LC-AAC, LPCM, MP3, Vorbis, WAV
Connectivity technology	Wireless
Cable length	1.8 m
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Current	2 A
Power source type	DC

Weight and Dimensions

Width	- mm
Height	142.8 mm
Weight	477 g
Diameter	96.4 mm
