HP 5528A User Manual

Model 5528A
Interconnection s, Turn-On
CONTENTS
SECTION
5
INTERCONNECTIONS
TURN-ON
INTRODUCTION
SAFETY INFORMATION
CONNECTING
THE LASER HEAD TO THE MEASUREMENT DISPLAY
CONNECTING SENSORS TO THE MEASUREMENT DI SPLAY
CONNECTING THE REMOTE CONTROL BOX TO THE MEASUREMENT DISPLAY
CONNECTING
AN HP PERSONAL COMPUTER AND / OR AN HP PLanER TO THE
MEASUREMENT DISPLAY
CH ECK I NG THE LINE - VOlTAGE SELECTION
CONNECT I NG THE SYSTEM TO THE POWER LINE
TURN-ON
INTRODUCTION
This User's Guide section presents the information you sh ould have 10 make the power and signal
connections required by the Laser Measurement System .
Some of the information in this Section is similar to that presenled in Section I, Section II, or
Section III of the SS28A 's Service Manual.
If
you are servicing the Laser Measurement System , or performing an Incoming inspection on it , we
recommend that
you refer to the S528A 's Servi ce Manual for all the information you need,
including connection information.
SAFETY INFORMATION
WARNING
BEFORE THE INSTRUMENT IS SWITCHED ON, ALL PROTECTIVE
EARTH TERMINALS. EXTENSION CORDS. AUTO - TRANS -
FORMER AND DEVICES CONNECTED TO IT SHOULD BE CON-
NECTED TO A PROTECTIVE EARTH GROUNDED SOCKET. ANY
INTERRUPTION OF THE PROTECTIVE (GROUNDING) CON-
DUCTOR (INSIDE OR OUTSIDE THE INSTRUMENT) OR DIS-
CONNECTING THE PROTECTIVE EARTH TERMINAL WILL CAUSE
A POTENTIAL SHOCK HAZARD THAT COULD RESULT IN
PERSONAL INJURY. (GROUNDING ONE CONDUCTOR OF A
TWO-CONDUCTOR
OUTLET IS NOT SUFFICIENT PROTECTION. )
WHENEVER IT IS LIkELY THAT THE PROTECTION HAS BEEN
IMPAIRED, THE INSTRUMENT MUST BE MADE INOPERATIVE
AND BE SECURED AGAINST ANY UNINTENDED OPERATION .
IF THIS INSTRUMENT IS TO BE ENERGIZED VIA AN AUTO -
TRANSFORMER (FOR VOLTAGE REDUCTION ) MAkE SURE THE
COMMON TERMINAL IS CONNECTED TO THE EARTH TER -
MINAL or THE POWER SOURCE .
S-1
