Editing Programs
This section describes how to reflect TP (timer preset values) and CP (counter preset values) in the user program and how to clear them.
Reflecting TP (Timer Preset Values) and CP (Counter Preset Values) in the User Program
Note: Even if you modify TP (timer preset values) and CP (counter preset values) using the function in "Monitoring Device Values" on page 7-32,
those changes are not reflected in the user program at that time. To reflect the changed preset values in the user program, you must stop the user
program and confirm the changes.
When you change TP (timer preset values) and CP (counter preset values) with the function in "Monitoring Device Values" on page
7-32 and attempt to leave device monitor mode, the following message is displayed.
1. Press the (ESC) button or the (OK) button to display the standard screen.
When TP (timer preset values) and CP (counter preset values) differ from the device values in the ROM, T/C is changed is
displayed on the standard screen.
To reflect or clear preset value changes, stop the user program. For the steps to stop the user program, see "Switching Run/Stop"
on page 7-9.
2. On the standard screen, press the (ESC) + (OK) buttons to display the system menu.
3. Select Edit Program with the (up) and (down) buttons and press the (OK) button.
4. Select T/C Preset Values and press the (OK) button.
5. Select Confirm with the (up) and (down) buttons and press the (OK) button.
The changed preset values are written to the user program in the ROM.
Timer/counter preset
values are changed.
Stopped
T/C is changed
2015/DEC/01/TUE
13:30:40
When the user program is stopped
When the user program is running
Running
T/C is changed
2015/DEC/01/TUE
13:30:40
Stopped
T/C is changed
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Run
Edit Program
External Memory
Configurations
T/C Change Status:
T/C is changed
Clear
Confirm
To Next Page
