FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 7-45
7: HMI F UNCTION
Uploading/Downloading the User Program
This section describes how to download the user program on the SD memory card to the CPU module and how to upload the user
program on the CPU module to the SD memory card when the user program is stopped.
Downloading the User Program (SD memory card –> CPU module)
Download the user program on the SD memory card to the CPU module.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select SD Card with the (up) and (down) buttons and press the (OK) button.
4. Select Program with the (up) and (down) buttons and press the (OK) button.
5. Select Download with the (up) and (down) buttons and press the (OK) button.
6. Select the zld file to download with the (up) and (down) buttons and press the (OK) button.
*1
*1 Files that can be selected to download are zld files stored in the PROGRAM folder on the SD memory card.
7. The following screen is displayed when the user program is being downloaded
*2
. When finished, the screen in step 4 is
displayed.
*2 When downloading the system software, the system is reset during the download and the screen is reset to the standard screen.
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
SD Card
Stop Access
Format
Recipe
Program
Download
Upload
File Name(.zld)
㸸
abcdefgh
