FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 A-1
APPENDIX
This appendix describes information such as a list of FC6A Series MICROSmart types, how to update the software, and how to
install the USB driver.
Type List
This section describes the types of FC6A Series MICROSmart modules, maintenance parts, manuals, and optional cables (sold
separately).
CPU Modules
All-in-One CPU Modules
*1 Screw fastened type
*2 Push-in type
Power
Voltage
Input Type Output Type
I/O Points
(Input Points/
Output Points)
Type No.
Terminal
Specification
100-240V
AC
24V DC input
shared sink/source
Relay output, 2 A/point
16 (9/7)
FC6A-C16R1AE
Removable terminal
block
(5.08 mm pitch)
*1
FC6A-C16R4AE
*2
24 (14/10)
FC6A-C24R1AE
*1
FC6A-C24R4AE
*2
40 (24/16)
FC6A-C40R1AE
*1
FC6A-C40R4AE
*2
24V DC
16 (9/7)
FC6A-C16R1CE
*1
FC6A-C16R4CE
*2
24 (14/10)
FC6A-C24R1CE
*1
FC6A-C24R4CE
*2
40 (24/16)
FC6A-C40R1CE
*1
FC6A-C40R4CE
*2
24V DC
24V DC input
shared sink/source
Transistor sink output
24V DC, 0.5 A/point
16 (9/7)
FC6A-C16K1CE
Removable terminal
block
(5.08 mm pitch)
*1
FC6A-C16K4CE
*2
24 (14/10)
FC6A-C24K1CE
*1
FC6A-C24K4CE
*2
40 (24/16)
FC6A-C40K1CE
*1
FC6A-C40K4CE
*2
Transistor protection source output
24V DC, 0.5 A/point
16 (9/7)
FC6A-C16P1CE
*1
FC6A-C16P4CE
*2
24 (14/10)
FC6A-C24P1CE
*1
FC6A-C24P4CE
*2
40 (24/16)
FC6A-C40P1CE
*1
FC6A-C40P4CE
*2
12V DC
12V DC input
shared sink/source
Relay output, 2 A/point
16 (9/7)
FC6A-C16R1DE
Removable terminal
block
(5.08 mm pitch)
*1
FC6A-C16R4DE
*2
40 (24/16)
FC6A-C40R1DE
*1
FC6A-C40R4DE
*2
Transistor sink output
12V DC, 0.5 A/point
16 (9/7)
FC6A-C16K1DE
*1
FC6A-C16K4DE
*2
40 (24/16)
FC6A-C40K1DE
*1
FC6A-C40K4DE
*2
Transistor protection source output
12V DC, 0.5A/point
16 (9/7)
FC6A-C16P1DE
*1
FC6A-C16P4DE
*2
40 (24/16)
FC6A-C40P1DE
*1
FC6A-C40P4DE
*2
