FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 9-15
9: A NALOG I/O M ODULES
Device Allocation
This section describes the allocation of analog I/O module devices.
Analog Input Module
The detailed device allocation for analog input modules is as follows.
For the parameter setting values, see "Analog Input Parameter Setting Values" on page 9-17.
Channel
Parameter R/W
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
I/O No.
Input
CH0
Analog input dataR+0+0+0+0+0+0
Analog input statusR+1+1+1+1+1+1
CH1
Analog input dataR+2+2+2+2+2+2
Analog input statusR+3+3+3+3+3+3
CH2
Analog input data R ― +4 +4 +4 +4 +4
Analog input status R ― +5 +5 +5 +5 +5
CH3
Analog input data R ― +6 +6 +6 +6 +6
Analog input status R ― +7 +7 +7 +7 +7
CH4
Analog input data R ――+8 ――+8
Analog input status R ――+9 ――+9
CH5
Analog input data R ――+10 ――+10
Analog input status R ――+11 ――+11
CH6
Analog input data R ――+12 ――+12
Analog input status R ――+13 ――+13
CH7
Analog input data R ――+14 ――+14
Analog input status R ――+15 ――+15
When use data register for setting parameters, the following data registers are used.
CH0
Signal type R/W +4 +8 +16 +8 +8 +16
Data type R/W +5 +9 +17 +9 +9 +17
Minimum value R/W +6 +10 +18 +10 +10 +18
Maximum value R/W +7 +11 +19 +11 +11 +19
Filter value R/W +8 +12 +20 +12 +12 +20
Thermistor constant (R0) R/W ―――――+21
Thermistor constant (T0) R/W ―――――+22
Thermistor constant (B) R/W ―――――+23
CH1
Signal type R/W +9 +13 +21 +13 +13 +24
Data type R/W +10 +14 +22 +14 +14 +25
Minimum value R/W+11+15+23+15+15+26
Maximum value R/W+12+16+24+16+16+27
Filter value R/W+13+17+25+17+17+28
Thermistor constant (R0) R/W ―――――+29
Thermistor constant (T0) R/W ―――――+30
Thermistor constant (B) R/W ―――――+31
CH2
Signal type R/W ― +18 +26 +18 +18 +32
Data type R/W ― +19 +27 +19 +19 +33
Minimum value R/W ― +20 +28 +20 +20 +34
Maximum value R/W ― +21 +29 +21 +21 +35
Filter value R/W ― +22 +30 +22 +22 +36
Thermistor constant (R0) R/W ―――――+37
Thermistor constant (T0) R/W ―――――+38
Thermistor constant (B) R/W ―――――+39
