FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 7-41
7: HMI F
UNCTION
SD Memory Card Maintenance
This section describes how to stop access to the SD memory card inserted into the CPU module and how to format the SD memory
card.
Stopping Access to the SD Memory Card
Access to the SD memory card inserted into the CPU module is stopped using the HMI module buttons.
Access to the SD memory card can be stopped regardless of whether the user programming is running or stopped.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select SD Card with the (up) and (down) buttons and press the (OK) button.
4. Select Stop Access with the (up) and (down) buttons and press the (OK) button.
5. Select Yes with the (down) button and press the (OK) button.
6. While the access to the SD memory card is being stopped, the screen below is displayed. When stopping the access is finished,
the screen in step
4 is displayed.
Notes:
Set the write-protect switch on the SD memory card to insert into the CPU module to the off position.
Insert and remove the SD memory card in the direction indicated on the CPU module.
Do not remove the SD memory card while the access to it is being stopped. There is a risk of damage to the SD memory card and the data
stored on it. Check that the SD memory card status indicator LED [SD] is off and then remove the SD memory card from the CPU module.
Running
13:30:40
2015/DEC/01/TUE
Stopped
2015/DEC/01/TUE
13:30:40
When the user program is stopped
When the user program is running
Run
Edit Program
External Memory
Configurations
Stop
External Memory
Device Monitor
Status Monitor
When the user program is stopped
When the user program is running
Stop Access
Format
Recipe
Program
Do you want to stop
SD card access?
No
Yes
