R4 to 37 kW Fixed Speed Modbus Table
Table 32: R4 To 37 kW Fixed Speed Modbus Table
Register
(40XXX)
Variable Read/Write Range Notes
1 Status/Control R/W See FIGURE 129
3 Package Discharge Pressure R
4 Sump Pressure R
7 Airend Discharge Temperature R
8 After-cooler Discharge Temperature R Low Ambient units only
10 Separator Pressure Drop R
16 After-cooler Discharge Pressure R Dryer units only
65 Running Hours MSB R
66 Running Hours LSB R
67 Loaded Hours MSB R
68 Loaded Hours LSB R
98 Rated Pressure R
100 Starter Type R 1-3 See Figure 130
101 Modulation Enabled R 0=Disabled
102 Service Level R 0 - 2 0=Level 0, 1=Level 1, 2=Level 2
103 Service Time Period R 1000 - 8000 Increments of 1000
104 Dryer Installed R 0=OFF
112 O ine Pressure R/W 75 - (rated+10) rated = rated pressure
113 Online Pressure R/W 65-(o ine-10) o ine = o ine pressure
114 Mode of Operation R/W 0 – 2 See Figure 130
115 Starter Time (seconds) R/W 5 – 30
116 Auto Restart Time (seconds) R/W 120 – 3600
117 Auto Restart ON/OFF R 0=OFF
118 Communication Control ON/OFF R 0=OFF
119 Remote Start/Stop Enable R 0=OFF
121 Power Out Restart Option (PORO) Enable R 0=OFF
122 PORO Time (seconds) R/W 10 - 600
123 Auto Start/Stop Delay Time (seconds) R/W 0 - 60
124 Low Ambient Temperature R/W 30 - 60 Degree F
125 Unloaded Stop Time R/W 10 - 30
128 Lead/Lag R/W 0=Lag
129 Lag O set R/W 0 - 45 psi
131 Lead/Lag Cycle Length (Hours) R/W 0 – 750
132 Scheduled Start (Day) R/W 0 - 9 See Figure 130
133 Scheduled Start (Hour) R/W 0 – 23
134 Scheduled Start (Minute) R/W 0 – 59
135 Scheduled Stop (Day) R/W 0 - 9 See Figure 130
136 Scheduled Stop (Hour) R/W 0 – 23
137 Scheduled Stop (Minute) R/W 0 – 59
255 Warning Code R See Figure 131
256 Trip Code R See Figure 131
400 Reset Web Logins R/W 0-1 Writing a 1 value will reset the web logins to
factory defaults. After the reset is performed
this value shall be set back to 0
