R5.5 to 37 kW Variable Speed Modbus Table
Table 33 : R5.5 TO 37 kW Variable Speed Modbus Table
Register
(40XXX)
Variable Read/Write Range Notes
1 Status/Control R/W See Figure 132
3 Package Discharge Pressure R
4 Sump Pressure R
10 After-cooler Discharge Pressure R
12 Airend Temperature R
19 Separator Pressure Drop R
20 Percent Capacity R
25 Motor Speed R
26 Motor Current R
28 DC Link Voltage R
30 Motor Voltage R
31 Package kW R
32 kW Hours R 0 – 999 Add to (mW hours * 1000)
65 Total Hours MSB R
66 Total Hours LSB R
98 Compressor Type R See FIGURE 133
99 Service Level R 0 - 2 0=Level 0, 1=Level 1, 2=Level 2
100 Service Time Period R 1000 - 8000 Increments of 1000
103 Dryer Installed R 0 = no dryer
112 Target Pressure R/W 65 - 145
113 Auto Stop Pressure R/W (T+1)-(T+10) T = target pressure
114 Immediate Stop Pressure R/W ASP–(ASP+10) ASP = auto stop pressure
117 Compare Savings To R/W 0 - 2 0=Geo, 1=Mod, 2=ON/OFF
121 Communication Control ON/OFF R 0=OFF
122 Remote Start/Stop ON/OFF R 0=OFF
123 Power Out Restart Option (PORO) ON/OFF R 0=OFF
124 PORO Time (seconds) R/W 10 - 600 See Figure 133
127 Scheduled Start - Day R/W 0 - 9 See Figure 133
128 Scheduled Stop - Day R/W 0 - 9
129 Scheduled Start (Hour) R/W 0 – 23
130 Scheduled Start (Minute) R/W 0 – 59
131 Scheduled Stop (Hour) R/W 0 – 23
132 Scheduled Stop (Minute) R/W 0 – 59
133 Rated Pressure R
251 VSD Software Version Number R Divide by 100
255 Warning Code R See Figure 134
256 Alarm Code History R See Figure 134
400 Reset Web Logins R/W 0-1 Writing a 1 value will reset the web logins to
factory defaults. After the reset is performed
this value shall be set back to 0
