HYDRAULICS
4181384 First Edition 6-17
6
Steering Circuit Schematic
See Figure 6-11.
Figure 6-11
1 Operating Pressure Oil to Raise/Lower
Circuit
4 Return Oil from Traction Drive Circuit
2 Return Oil from Raise/Lower Circuit 5 Return Oil from Brake Release Valve
3 Operating Pressure Oil to Mow Circuit
TN1182
Inlet Oil
Operating Pressure Oil
Return Oil
1
2
3
Steering Valve
Steering
Cylinder
Oil Cooler
Cutting Unit Pump
Steering Pump
Hydraulic
Oil Tank
Lift and
Steering
Relief Valve
L
R
P
T
E
4
5
Steering
Direction
Valve Body
To Next Page
