Rev. 2.0
Maintenance Guide
14-42
14-8-1-2. Setting the Jumpers/Switches
The jumpers and switches except for SW1 have already been set at the delivery. Before
mounting the PCB, check the jumper and switch settings.
部がスイッチの設定、及びリセプタクル
の取り付け位置となります。
SW2
O
N
1
2
3
4
SW5
O
N
1
2
3
4
5
6
7
8
SW3
O
N
1
2
3
4
5
6
7
8
SW6
O
N
1
2
3
4
W1
1
2
3
W2
1
2
3
14-8-1-3 Adjusting the Volumes
The volumes have already been adjusted at the delivery of the PCB. So, mount the PCB in the
machine and check the set voltage values. For details, see “KE-3010/20V/20VR_QA Table,
Chapter16._Adjustment of head VAC level and temperature sensor output level”.
portion shows the switch set position and receptacle mounting position.
