9-14
9-16. X unit
The X unit, which is a driving unit to transfer components to the shuttle, is driven independently.
You set the transfer distance and select continuous or single operation mode.
Starting X unit
Select “15. X Unit” in the menu.
Use → and ← buttons (for setting in unit of step) and ↑ and ↓ buttons (for setting in unit of
0.1mm) to set the transfer distance. Press the ENTER button.
Use ← and ↓ buttons to decrement the value, and → and ↑ buttons to increment.
Fig. 9-16-1 Setting of transfer distance
Selecting operation mode
Use → and ← buttons to move the cursor ∗ and select continuous or single operation mode.
Press the ENTER button.
Fig. 9-16-2 Selection of operation
Starting operation
Press the ENTER button to start the operation.
Fig. 9-16-3 Operation in progress
Finishing operation
In the single operation mode, the display returns to the operation selection screen when
the operation is completed.
In the continuous operation mode, press the CANCEL button to return to the operation
selection screen .
Another pressing the CANCEL button changes the display to the state and then to the
menu screen.
The X unit moves to the initial position when the system returns to the menu screen.
Distance 596.0mm
∗Cont One
Moving･･･
