1-1
1
How to Set Up the System
1-1. Removing metal fixtures for transport
Remove the stopper that secures the X-axis carriage using the M4 hexagon socket head bolt
.
Then remove FIX BR that secures the head section using the M3 hexagon socket head bolt .
Note: It may happen that the head section is lowered if FIX BR is removed with no air
present inside. Be extremely aware of the risk that the head section should be
broken if you move the X-axis carriage by hand in the above situation.
To Next Page
