Keithley 3700A Series Reference Manual

Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-12 3700AS-901-01 Rev. D/June 2018
Details
This function returns the value of the bit in value at index. This is the same as returning value with
all other bits set to zero (0).
The least significant bit of value is at index position 1; the most significant bit is at index
position 32.
If the indexed bit for the number is set to zero (0), the result will be zero (0).
Example
testResult = bit.get(10, 4)
print(testResult)
The binary equivalent of decimal 10 is 1010. If you
get the bit at index position 4, the returned decimal
value is 8.
Output:
8.00000e+00
Also see
Bit manipulation and logic operations (on page 9-21)
bit.clear() (on page 11-11)
bit.set() (on page 11-13)
bit.test() (on page 11-15)
bit.toggle() (on page 11-15)
bit.getfield()
This function returns a field of bits from the value starting at the specified index position.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
No
Usage
result = bit.getfield(value, index, width)
result
Result of the bit manipulation
value
Specified number
index
One-based bit position within value to get (1 to 32)
width
The number of bits to include in the field (1 to 32)
Details
A field of bits is a contiguous group of bits. This function retrieves a field of bits from value starting at
index.
The index position is the least significant bit of the retrieved field. The number of bits to return is
specified by width.
The least significant bit of value is at index position 1; the most significant bit is at index
position 32.
