Section 11: TSP command reference Series 3700A System Switch/Multimeter Reference Manual
11-426 3700AS-901-01 Rev. D/June 2018
Also see
None
tsplink.trigger[N].mode
This attribute defines the trigger operation and detection mode.
Instrument reset
Recall setup
TSP-Link trigger N reset
Create
configuration script
Save setup
Usage
mode = tsplink.trigger[N].mode
tsplink.trigger[N].mode = mode
The trigger line (1 to 3)
Details
This attribute controls the mode in which the trigger event detector and the output trigger generator
operate on the given trigger line.
The setting for mode can be one of the following values:
Allows direct control of the line as a digital I/O line.
Detects falling-edge triggers as input. Asserts a TTL-low pulse
for output.
If the programmed state of the line is high, the
tsplink.TRIG_RISING mode behaves similarly to
tsplink.TRIG_RISINGA.
If the programmed state of the line is low, the
tsplink.TRIG_RISING mode behaves similarly to
tsplink.TRIG_RISINGM.
Use tsplink.TRIG_RISINGA if the line is in the high output
state.
Use tsplink.TRIG_RISINGM if the line is in the low output
state.
Detects rising- or falling-edge triggers as input. Asserts a
TTL-low pulse for output.
tsplink.TRIG_SYNCHRONOUSA
Detects the falling-edge input triggers and automatically
latches and drives the trigger line low.
Detects the falling-edge input triggers and automatically
latches and drives the trigger line low. Asserts a TTL-low pulse
as an output trigger.
tsplink.TRIG_SYNCHRONOUSM
Detects rising-edge triggers as an input. Asserts a TTL-low
pulse for output.
Detects rising-edge triggers as input. Asserts a TTL-low pulse
for output.
Edge detection as an input is not available. Generates a
TTL-high pulse as an output trigger.
