11.3
Section 11
Reassembly
11
Hitch Pin
Thrust
Washer
Governor
Cross Shaft
Index Flat
Cup &
Washer
Governor Gear
Assembly
Figure 11-8. Installing Governor Shaft.
4. Install the second fl at washer onto the sha .
Position the sha so the fl at index end of the sha
faces to the le (9 o'clock position) and install the
hitch pin so the end of the pin comes in contact
with the raised boss on the housing, limiting
inward movement of the sha . See Figure 11-9.
Gasket
Surface
Figure 11-9. Installing Thrust Washer and Hitch
Pin.
CH395
1. Assemble the governor gear pin into the governor
gear so the pin rim is held in place by the weight
retainers. See Figure 11-10.
Figure 11-10. Governor Gear Assembly.
2. Place the thrust washer on the governor gear
sha in the closure plate. Push the governor gear
onto the sha . See Figure 11-11.
Figure 11-7. Installing Governor Gear Assembly.
3. Install one thrust washer onto the governor cross
sha and slide the sha up through the inside of
the crankcase. See Figure 11-8.
Pin Rim
Weight
Retainers
Governor
Gear
Governor
Gear Shaft
Thrust
Washer
Figure 11-11. Install Governor Gear Assembly.
