Kohler Command PRO CH440 Service Manual

1.7
Section 1
Safety and General Information
1
Dimensions in millimeters.
Inch equivalents shown in ( ).
Figure 1-6. Typical Engine Dimensions-CH270 With Low-Profi le Air Cleaner.
434.13
[17.092]
322.61
[12.701]
260.38
[10.251]
265.70
[10.461]
261.29
[10.287]
323.45
[12.734]
3/4” STRAIGHT
PTO
26.48
[1.043]
MOUNTING
FACE
APPROXIMATE
CENTER OF
GRAVITY
47.11
[1.855]
2X Ø 10.00
[0.395]
79.99
[3.149]
CYLINDER
35.70
[1.406]
39.33
[1.548]
5.50
[0.217]
2X Ø 10.00 X 15.50 SLOT
[0.394] X [0.610]
APPROXIMATE
CENTER OF
GRAVITY
221.31
[8.713]
30.
00
[1.181]
106.00
[4.173]
66.00
[2.598]
162.00
[6.378]
65.10
[2.563]
32.55
[1.281]
248.83
[9.796]
65.10
[2.563]
32.55
[1.281]
88.00
[3.465]
39.37
[1.550]
METRIC FLANGE:
4X M8 X 1.25-6H 15
SAE A FLANGE:
4X 5/16-24 UNF 2B 15
METRIC FLANGE:
M8 X 1.25-6H THRU
SAEAFLANGE:
4X 5/16-24 UNF 2B 15
