Kohler Command PRO CH440 Service Manual

1.10
Section 1
Safety and General Information
317.22
[12.49]
404.76
[15.94]
155.00
[6.102]
452.02
[17.796 ]
344.91
[13.579]
323.59
[12.74]
411.13
[16.186]
Ø1
STRAIGHT
PTO
40.00
[1.575]
21.32
[0.839]
CYLINDER
2X Ø 11.00 X 28.00 SLOT
[0.433] X [11.02]
2X Ø 11.25
[0.443]
128.83
[5.072]
3.75
[0.148]
SECONDARY
MOUNTING FACE
39.70
[1.563]
AIR CLEANER
COVER REMOVAL
CENTER OF
GRAVITY
176.82
[6.962]
106.82
[4.206]
73.82
[2.906]
17.00
[0.669]
195.50
[7.697]
105.00
[4.134]
4X 45°
4X 3/8-16 UNC 2B INCH
18 MM FULL THREAD
70.00
[2.756]
133.50
[5.256]
127.00
[5.000]
165.10
[6.500]
CENTER OF
GRAVITY
35.00
[1.378]
441.93
[17.399]
466.62
[18.371]
WITH US
50-STATE
GAS CAP
438.41
[17.260]
6.00
[0.236]
US 50-STATE
GAS CAP
REMOVAL
103.00
[4.055]
55.80
[2.20]
6.00
[0.240]
Ø
GAS CAP
REMOVAL
ALL AROUND
2X 30°
METRIC FLANGE:
6X M8 X 1.25-6H TAP 18 MIN.
6X 5/16-24 UNF 2B INCH 18 MIN.
Ø
Figure 1-9. Typical Engine Dimensions-CH440.
Dimensions in millimeters.
Inch equivalents shown in ( ).
