bizhub C554/C454/C364/C284/C224 17-21
17
Tips
- This item is available when the Finisher FS-534 and Saddle Stitcher SD-511 are installed.
- This item is available when the Finisher FS-535 and Saddle Stitcher SD-512 are installed (only for
bizhub C554).
- Make adjustment while checking paper folded at a displaced position.
- The value you set by selecting [All] in [Paper Size] will be added to the setting for each paper size.
[Tri-Fold Output Setting]
To display: [Utility] - [Administrator Settings] - [System Settings] - [Expert Adjustment] - [Finisher Adjustment]
- [Tri-Fold Output Setting]
Use this option to select whether to output tri-folded paper to the normal position or a position further away
from the normal position set for this machine.
[Normal Output] is specified by default.
Tips
- This adjustment is possible when the Finisher FS-535 and Saddle Stitcher SD-512 are installed in
bizhub C554.
[Punch Vertical Position Adjustment]
To display: [Utility] - [Administrator Settings] - [System Settings] - [Expert Adjustment] - [Finisher Adjustment]
- [Punch Vertical Position Adjustment]
If the positions of the punch holes on the paper are displaced vertically, use this option to adjust the punch
hole positions.
Copy after configuration, then repeat adjustments as required.
Tips
- This adjustment is possible when the Finisher FS-535 and Punch Kit PK-521 are installed in bizhub
C554.
- Make adjustments while checking paper punched at a displaced position.
- The value you set by selecting [All] in [Paper Size] will be added to the setting for each paper size.
Settings Description
[Paper Size] Select the size of paper subject to punch hole position adjustment.
[Adjust Value] Enter an adjustment value between -5.0 and 5.0 mm by tapping [-] and [+].
• [-]: Move the punch position downward.
• [+]: Move the punch position upward.
[0.0 mm] is specified by default.
