bizhub C554/C454/C364/C284/C224 17-23
17
[Punch Regist Loop Size Adjustment]
To display: [Utility] - [Administrator Settings] - [System Settings] - [Expert Adjustment] - [Finisher Adjustment]
- [Punch Regist Loop Size Adjustment]
If the positions of the punch holes on the paper are not in parallel with the paper edge, use this option to
correct the obliquity of the paper to make them parallel.
In bizhub C554: This adjustment is possible when the Finisher FS-535 is installed.
This adjustment is possible when the Finisher FS-534 and Punch Kit PK-520, or the Finisher FS-533 and
Punch Kit PK-519 are installed.
Tips
- Make adjustment while checking paper punched at a displaced position.
[Punch Edge Sensor Adjustment]
To display: [Utility] - [Administrator Settings] - [System Settings] - [Expert Adjustment] - [Finisher Adjustment]
- [Punch Edge Sensor Adjustment]
Use this option to adjust the sensor of the Punch function to detect the edge of the paper.
Press Start to start adjustment.
Tips
- This adjustment is possible when the Finisher FS-535 and Punch Kit PK-521 are installed in bizhub
C554.
Settings Description
[Finisher]/[Finisher (Z-
Fold)]/[Post Inserter Feeder
Upper Tray]/[Post Inserter
Feeder Lower Tray]
Select the position subject to paper inclination adjustment.
• [Finisher]: This adjustment is possible when the Punch Kit PK-521 is
installed.
• [Finisher (Z-Fold)]: This adjustment is possible when the Z Folding Unit
ZU-606 is installed.
• [Post Inserter Tray (Upper)]: This adjustment is possible when the
Punch Kit PK-521 and Post Inserter are installed.
• [Post Inserter Tray (Lower)]: This adjustment is possible when the
Punch Kit PK-521 and Post Inserter are installed.
[Paper Type] Select the type of paper that is used to adjust the inclination.
[Adjust Value] Enter an adjustment value by tapping [-] and [+].
• [+]: Tap this key to adjust the inclination of the paper.
• [-]: Tap this key if it is not possible to adjust the inclination with [+] or
paper creases.
The available adjustment value is between -5.0 mm and 5.0 mm (other than
[Finisher (Z-Fold)]) or between -16.0 mm and 16.0 mm ([Finisher (Z-Fold)]).
[0.0 mm] is specified by default.
Settings Description
[Paper Type] Select the type of paper that is used to adjust the inclination.
[Adjust Value] Enter an adjustment value between -4 and 4 by tapping [-] and [+].
• [+]: Tap this key to adjust the inclination of the paper.
• [-]: Tap this key if it is not possible to adjust the inclination with [+] or
paper creases.
[0] is specified by default.
