WaveSurfer DSO
WS-OM-E Rev B 19
Sensitivity: 50 ohms: 1 mV/div to 2 V/div; 1 Mohms: 1 mV/div to 10 V/div
DC Gain Accuracy: +/-(1.5% + 0.5% of full scale)
Offset Range:
+/-1 V @ 1.0 mV to 49 mV/div
+/-10 V @ 50 mV to 0.49 V/div
+/-100 V @ 0.5 V to 10 V/div
Offset Accuracy: +/-(1.0% + 0.5% of full scale + 1 mV)
Horizontal System
Timebases: Internal timebase common to 4 input channels
Time/div Range:
WaveSurfer 454/452 200 ps to 1000 s/div
WaveSurfer 434/432 500 ps to 1000 s/div
WaveSurfer 424/422 1 ns to 1000 s/div
Roll Mode 200 ms 1000 s/div
Math & Zoom Traces: 4 independent zoom traces; 1 math/zoom trace
Clock Accuracy: </= 10 ppm
Interpolator Resolution: 5 ps
Acquisition System
Single-shot Sample Rate/Ch: 1 GS/s
Sample Rate (RIS mode): 50 GS/s
2 Channel Max.: 2 GS/s
Standard Record Length: 500 kpts/Ch (interleaved); 250 kpts/Ch (all channels)
Max. Record Length (optional): 2 Mpts/Ch (interleaved); 1 Mpts/Ch (all channels)
Standard Capture Time: up to 250 s at full sample rate
Max. Capture Time (optional): up to 1 ms at full sample rate
Acquisition Processing
Averaging: Continuous averaging to 1 million sweeps
