WaveSurfer DSO
WS-OM-E Rev B 83
3. Touch inside the Current folder data entry field and use the pop-up keyboard to enter
the path to the folder that contains the file you want to delete. Or touch the Browse
button and navigate to the folder.
4. Once you have located the folder, touch the Empty Folder button.
To Create a Folder
1. Touch File in the menu bar, then Disk Utilities... in the drop-down menu.
2. Touch the Create button
in the "Disk Utilities" dialog.
3. Touch inside the Current folder data entry field and use the pop-up keyboard to enter
the path to the directory you want to create the folder in, and the name of the folder.
4. Touch the Create Folder button.
PRINTING AND FILE MANAGEMENT
Printing
To Set Up the Printer
1. In the menu bar, touch File, then Print Setup... in the drop-down menu. The Utilities
Hardcopy dialog opens.
2. In the dialog area, touch the Printer icon
.
3. Under Colors, touch the Use Print Colors checkbox if you want the traces printed on a
white background. A white background saves printer toner. (You can change the printer
colors in the Preference dialog;)
4. Touch inside the Select Printer field. From the touch pad pop-up choose the printer you
want to print to. Touch the Properties button to see your printer setup.
5. Touch the icon for the layout Orientation you want: portrait or landscape.
6. Touch the Grid Area Only checkbox if you do not need to print the dialog area and you
only want to show the waveforms and grids.
To Print
You can print in one of three ways:
1. Press the printer button on the front panel:
2. In the menu bar, touch File, then Print in the drop-down menu.
3. Touch the Print Now button in the "Hardcopy" dialog
Adding Printers and Drivers
Note: If you want to add a printer driver, the driver must first be loaded on the scope.
1. In the menu bar, touch File, then Print Setup... in the drop-down menu. The Utilities
