Operator's Manual
44 WS-OM-E Rev B
Auxiliary Output Signals
In addition to a standard 1 V, 1 kHz calibration signal on the front panel, the following signals can
be output through the AUX OUTPUT connector at the rear of the scope:
Trigger Out -- can be used to trigger another scope.
Trigger Enabled -- can be used as a gating function to trigger another instrument when
the scope is ready.
Pass/Fail -- allows you to set a pulse duration from 1 ms to 500 ms; generates a pulse
when pass/fail testing is active and conditions are met.
Aux Output Off -- turns off the auxiliary output signal.
To Set Up Auxiliary Output
1. In the menu bar, touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch the Aux Output tab.
3. Touch one of the buttons under Use Auxiliary Output For.
SAMPLING MODES
Depending on your timebase, you can choose either Single-shot (Real Time) ,
RIS
, or Roll mode sampling.
To Select a Sampling Mode
1. In the menu bar, touch Timebase, then Horizontal Setup... in the drop-down menu.
2. In the "Horizontal" dialog, touch a Sample Mode button.
