LeCroy WAVESURFER User Manual

Operator's Manual
20 WS-OM-E Rev B
Enhanced Resolution (ERES) -- optional with MathSurfer package: from 8.5 to 11 bits vertical
resolution
Envelope (Extrema) -- optional with MathSurfer package: Envelope, floor, roof for up to 1
million sweeps
Triggering System
Modes: Normal, Auto, Single, and Stop
Sources: Any input channel, External, Ext/10, or Line; slope, level, and coupling are unique to
each source (except Line). Line input is not available for battery or DC operation.
Slope: CH1 to CH4, Ext, Ext/10: Positive, Negative, Window; Line (except DC/battery power):
Positive, Negative
Coupling Modes: AC, DC, HF, HFRej, LFRej (except Line trigger)
Pre-trigger Delay: 0 to 100% of horizontal time scale
Post-trigger Delay: 0 to 10,000 divisions
Holdoff by Time or Events: Up to 20 s, or from 1 to 99,999,999 events
Internal Trigger Range: +/-5 div from center
External Trigger Range: EXT/10 +/-5 V; EXT +/-500 mV
External Trigger Impedance: 50 ohms, 1 Mohms
Basic Triggers
Edge/Slope/Line: Triggers when the signal meets the slope (positive, negative, window) and
level condition.
SMART Triggers -- Standard
Glitch: Triggers on positive or negative glitches with widths selectable from 600 ps to 20 s or on
intermittent faults.
Width: Triggers on positive or negative glitches with widths selectable from 2 ns to 20 s or on
intermittent faults. Includes exclusion mode (trigger on intermittent faults by specifying the normal
width period).
Logic (Pattern): Logic combination (AND, NAND, OR, NOR) of 5 inputs (4 channels and external
trigger input). Each source can be high, low, or don't care. The High and Low level can be
selected independently. Triggers at start or end of pattern.
TV -- Composite Video: Triggers selectable fields (1, 2, 4, or 8), positive or negative slope, for
NTSC, PAL, SECAM, or non-standard video (up to 1500 lines).

LeCroy WAVESURFER Specifications

General

Input Coupling	AC, DC, GND
Interface	USB, LAN, GPIB (optional)
Channels	4
Display	10.4" LCD
Vertical Resolution	8 bits
Input Impedance	1 MΩ || 50 Ω
Max Input Voltage	400 Vpk (1 MΩ)
Trigger Modes	Edge, Pattern
Bandwidth	200 MHz to 1 GHz

Summary

HOW TO USE ON-LINE HELP

Instrument Help

Accessing help specific to instrument controls and features via dedicated buttons or menus.

Windows Help

Accessing help for the underlying Windows operating system features by minimizing the scope application.

WARRANTY

Warranty and Service

Details warranty terms, conditions, and service procedures.

SPECIFICATIONS

Vertical System

Specifications for vertical signal acquisition.

Horizontal System

Specifications for horizontal timebase.

Triggering System

Specifications for trigger functionality.

INSTALLATION

Hardware Installation

Instructions for physical setup and connections.

CONNECTING TO A SIGNAL

ProBus Interface

Details the ProBus probe connection system.

SAMPLING MODES

Single-shot sampling mode

Explanation of single-shot acquisition.

VERTICAL SETTINGS AND CHANNEL CONTROLS

Adjusting Sensitivity and Position

How to adjust vertical gain and offset.

Coupling

Options for signal coupling (AC, DC, GND).

TIMEBASE AND ACQUISITION SYSTEM

Timebase Setup and Control

How to configure timebase settings.

TRIGGERING

Simple Triggers

Covers basic edge triggering.

SMART Triggers

Details advanced trigger types like Glitch and Width.

DISPLAY FORMATS

Display Setup

Configuring grid, intensity, and line styles.

Persistence Setup

Using persistence to view waveform history.

SAVE AND RECALL

Saving and Recalling Scope Settings

Procedures for saving/loading instrument setups.

PRINTING AND FILE MANAGEMENT

Printing

Setting up and performing print operations.

WAVEFORM MEASUREMENTS

Measuring with Cursors

Using cursors for precise measurements.

Parameter Calculations

Explains various waveform parameters and their calculation.

WAVEFORM MATH

Introduction to Math Traces and Functions

Overview of applying mathematical operations to waveforms.

FFT

Details the Fast Fourier Transform analysis.

UTILITIES

Status

Accessing system status and configuration.

Remote communication

Setting up network communication for remote control.

Options

Preferences

Customizing instrument behavior and settings.
